SIMPLE PANEL WITH EASY SETUP

The cutting setup for wide range of materials is quite simple with this hydraulic saw blade feed model. Programming during cycle cuts is allowed for quick work.

LARGE FRONT TABLE

The front work table is deep and wide to allow for hoisting by crane operation without any saw frame interference.

INDEXING TABLE WITH ROLLERS

The material is smoothly fed on the index roller table that is designed to withstand the heaviest of material.

SENSOR/STOPPER INITIAL INDEXING

The initial indexing to start cycle cut is selectable; both quick laser sensor method and accurate bumper-stopper method available.

AUTOMATIC INFEED SETUP ---

One touch switch allows work feed setup (saw frame raises, all vises open) and work remnant retraction automatic for operator ease.

BACK GAUGE FUNCTION

The index vise can be also used as a back gauge for convenient accurate single cutting operations.

HYDRAULIC INSERT TIPS

The guide insert tips are hydraulically clamped to the saw blade with the proper pressure to ensure an accurate and square cutting.

BLADE DEVIATION DETECTOR

This detector monitors the blade for any minor deviation during cutting and halts the machine if out of tolerance.

LINKED SAW GUIDE

The movable saw guide is linked with the movable vise jaw position to be as close to the work piece as possible. This ensures optimal cutting conditions.

FORWARD-REVERSE TWIN BRUSHES

The twin saw brushes run mutually opposite way to wipe out saw chips thoroughly for accurate cuts and longer blade life.

SPLIT VISE

The main vise is split to be able to clamp even the shortest of pieces securely on both sides of the saw blade.

SHIFTING INDEX SADDLE

When indexing, the index saddle slightly shifts material aside to avoid scratching the surface by the vise, which is good for stainless / cold-finished steel bars.
